Key Features	Applications
Broad wavelength tuning rang (S+C+L) Excellent power and wavelength stability > 60 dB signal-to-noise ratio Small form factor	Test and measurement Fiber sensor systems Monitor DWDM thin film coating

1550 nm Tunable Fiber Laser Specifications (1 µm is also available from
1025-1090 nm)

Item	Min	Typical	Max	Unit
Output power	1		15	dBm
Output power stability			± 0.02	dB
Spectral bandwidth		0.1		nm
Wavelength range	1490		1610	nm
OSNR	60			dB
Return loss		30		dB
Operating temperature	0		40	oC
Tuning mechanism		mechanical
Power consumption			4	W
Size	170x120x19 (module) 235x240x100 (instrument)			mm

Note: Electrically tuning is available upon request.

---

PolarOnyx, Inc. reserves the right to change specs at any time without notice.

Broad wavelength tunable fiber laser module and instrument.
