PolarOnyx has developed a series of high power ultra-short pulsed fiber lasers operating up to 10W at 1 and 2 micron spectral region and up to 5 W at 1.55 micron spectral region. These modules/instruments provide a turn key solution and maintenance free operation.

• Download Data Sheet

Key Features	Applications
< 200 fs pulse High power up to 10 W Turn key/RS 232 Competitive price	Material processing & ablation Ultrafast phenomena research Biomedical research and development Nonlinear spectroscopy and microscopy

1 micron High Power Mode Locked Femtosecond Fiber Laser Specifications

Item	Min	Typical	Max	Unit
Output average power		1, 5, 8	10	W
Pulse width	80	100-250	500	fs
Wavelength range*	1025	1030, 1047, 1053, 1064	1100	nm
Pulse repetition rate	10		200	MHz
Output type		Free space
Size	430x130x560 (instrument)			mm

* Tunable wavelength is available upon request. Integrated SHG (1 W, 515 nm/532 nm) is available.

1.55 micron and 2.0 micron High Power Mode Locked Femtosecond Fiber Laser Specifications

Item	Min	Typical	Max	Unit
Output average power		1	5	W
Pulse width	150	300	500	fs
Wavelength range*	1530 1950	Fixed Fixed	1600 2050	nm nm
Pulse repetition rate	10		300	MHz
Output type		Free space or fiber output
Size	430x130x560 (instrument)			mm

* Tunable wavelength is available upon request. Integrated SHG (780 nm, 1 W) is available upon request.

---

PolarOnyx, Inc. reserves the right to change specs at any time without notice.

Instrument (top) and autocorrelator trace (bottom) of a high power mode-locked fiber laser
